SunMaster XS6500
The sun as your very own power system
More power from the sun under all conditions, with an exceptional degree of reliability.As one of the pioneers in the grid connected solar industry, Mastervolt has a long track record in developing and manufacturing high-quality solar inverters that transform solar power into valuable energy.The SunMaster XS series solar inverter is the result of 20 years of expertise and practical experience, making sure you get the most out of your PV system.
Flexible design
- Compatible with any type of solar module
- Country selection via LCD
- Integrated transformer
High yield
- 100% power up to 45 °C
- High efficiency using HF technology
- More production due to early startup and late shutdown
- Unique adaptive cooling technology
Advanced monitoring
- Large user-friendly LCD
- 30 day kWh memory as standard
- Free plug & play software
- Extensive monitoring solutions available
Easy and safe installation
- MC connections
- Mounting brackets included
- Integrated DC switch available
- Lightweight
Reliable
- Standard 5 years warranty with optional 10 or 20 years
- Designed based on a proven Mastervolt concept
- Long life due to advanced cooling
- Outstanding price/quality ratio
Product code: 131016500
Downloads
Brochures
SunMaster XS series
Brochures
Solar Image Brochure (general)
Brochures
solar Monitoring
Certificates
Certificado de sincronización de ...
Certificates
TF 3.2.1 declaration of conformity
Certificates
Verklaring van conformiteit met document...
Certificates
Suitability of thin film PV modules
Certificates
EDF Fiche C5 SunMaster XS 6500 (Fran&cce...
Certificates
AS4777 Certificate
Certificates
EC Declaration of Conformity Sunmaster X...
Certificates
G83/1 certificate
Certificates
Compilazione Allegato O Enel
Certificates
Dichiarazione per differnziale
Certificates
VDE0126
Certificates
20110222 VDEW Konformitätserklarung
Certificates
Certificates
UTE C 15-712-1 compliance statement
Certificates
Grid connection certificate for Greece
Certificates
RD 1663/2000
Certificates
First solar compatibility
Certificates
G59/2 certificate
Certificates
dichiarazione di conformità per deliber...
Certificates
VDE4105 Konformität und F2,F3,F4,G2,G3
Installation manuals
Quick installation and commissioning Sun...
Manuals
Bedienungs- und Installationsanleitung S...
Product notifications
Reactive Power info bulletin
Product notifications
Functional grounding information bulleti...
Product notifications
Mastervolt Produktportfolio Übersicht
Software
design, can be run locally on any PC wit...
Software
Masterlog (Beta)
3D product drawings
3D-drawing Sunmaster XS6500 (zipped STEP...
Specifications
| General specifications | ||
| Safety class | class I (metal housing with earth connection) |
|
| Max. output power | 5000 W |
|
| Output frequency range | 45-65 Hz, country dependent |
|
| Max. input power | 5525 W |
|
| AC connection | 2.5-10 mm² terminal block |
|
| Galvanic isolation | class II (safety transformer) |
|
| EU efficiency | 94.6 ( at 370 V) % |
|
| Max. efficiency | 95.6 % |
|
| MPP efficiency (Fraunhofer algortithm) | 99,9 % |
|
| Dimensions, hxwxd | 545x356x145 mm |
|
| Weight | 15 kg |
|
| Approvals | ce |
|
| Nat. grid requirements | VDE 0126-1-1 / DK5940 / RD1663-2000 / K SC 8536 / G83-1 compliant |
|
| Number of MPP trackers | 2 |
|
| Safety devices DC side | isolation resistance monitoring • overvoltage detection • inverse polarity protection • curren |
|
| Safety devices AC side | current limitation • DC injection protection • short circuit protection (ceramic fuse) • over- |
|
| User interface | integrated LCD - display with backlight, 4 buttons and bright diagnostic LED. All relevant AC and DC |
|
| Product warranty | 5 year |
|
| Technical specifications | ||
| DC current injection | VDE0126-1-1 / DK5940 / G83 / KSC8536 compliant |
|
| Harmonic distortion typical | < 3% at full power |
|
| Power factor control | > 0.99 |
|
| Temperature range (ambient temp.) | -20 to 45 °C |
|
| Relative humidity | max. 95% (non condensing) PCB has anti-moisture coating |
|
| Protection degree | 44 |
|
| DC connection | 2 sets of MultiContact (4 mm) connectors |
|
| Grid voltage | 230 V AC single phase (184 - 265 V, country dependent) |
|
| Nominal output current | 25 A |
|
| Fuse | internal PCB fuse |
|
| External communication | 2 surge protected RS485 connections. 2 Masterbus connections. Max. 20 XS units can be connected to 1 |
|
| Island protection | redundant voltage and frequency window monitoring. Independent cut-off by means of 2-pole relay and |
|
| Temperature protection | thermal switch-off at internal over temperature |
|
